To size a power supply you must match the supply voltage to the voltage of your outputs. You must also add up the wattages of all the outputs that will be on at any given time, as well as any watts required by the controller and it's internal amplifier.
Determine the voltage of your output devices, generally these are solenoids or relays. The voltage must be 12 or 24 volts DC to be used with our solid-state output products. The voltage of your power supply MUST match the voltage of your output devices!
Choosing a Voltage
If you are going to use the solid-state outputs on our products we highly recommend you use 24 volt solenoids and relays. The reason for this is the current capacity of solid-state outputs. Each solid-state output has a current limit of 0.5 amps, which is 6 watts at 12 volts, or 12 watts at 24 volts. There are also fuses inside each solid-state product that protect the driver chip from overheating, one fuse for every eight outputs. This prevents the total current draw on a bank of eight outputs from exceeding 12 watts at 12 volts, or 24 watts at 24 volts. Therefore when you use 24 volt solenoids you can get away with using twice as much wattage without exceeding the current limitations. This is a common limitation for solid-state controllers from almost every manufacturer.
Another factor to consider when choosing a voltage is the product's internal amplifier. The FlexMax's amplifier will be loudest at 24 volts. It's still pretty loud at 12, but it can only give you the full 50 watts at 24 volts. Please note that the PicoBoo amplifiers can only handle 12 volts, using a 24 volt supply on those will burn them out.
The wattage of your supply must meet or exceed the total wattage required by all your outputs plus the controller and its internal amplifier if it has one. To do this, add up the wattage of all your valves, this should be clearly marked on the label of each valve, 5 to 6 watts is common. You may not have all the outputs turned on at any one time, so you can cheat a bit here. Add up the wattages of the most outputs that will be turned on at any given time. Now add the wattage for your controller, 3 watts is a safe bet here. If your controller has an internal amplifier, add up the wattage of that too. That's 50 watts for the FlexMax's amplifier.
Let's say you have six 24VDC 6 watt valves connected to a controller, but a maximum of three of them will be turned on at any given time.
18 watts (3 x 6 watt solenoid valves) 3 watts (controller) ------------------ 21 watts total
Example 2 Let's say you have twelve 24VDC 6 watt valves connected to a FlexMax, a maximum of nine of them will be turned on at any given time. We will be using the internal amplifier as well.
54 watts (9 x 6 watt solenoid valves) 3 watts (FlexMax) 50 watts (FlexMax amplifier) ------------------ 107 watts total
WARNING: HYDRAULIC AND PNEUMATIC POWER SYSTEMS CAN FAIL THROUGH MISUSE, AGE OR MALFUNCTION. THE SYSTEM DESIGNER
IS WARNED TO CONSIDER THE FAILURE MODES OF ALL COMPONENTS USED IN THE DESIGN AND ENGINEERING OF ALL SYSTEMS AND TO PROVIDE ADEQUATE
SAFEGUARDS TO PREVENT PERSONAL INJURY OR DAMAGE TO EQUIPMENT IN THE EVENT OF SUCH FAILURES
