24 Channel DMX Solid State Decoder

Item #HB-7B1W

IN STOCK

Decode DMX signal into solid state outputs! Trigger any low voltage device with DMX!

As low as $7999

Customize 24 Channel DMX Solid State Decoder

Optional Power Supply

Optional Adapter for Power Supply

1 x Female Power Supply Adapter with wires + $2.99

Your Customization

24 Channel DMX Solid State Decoder

Summary

description

NOTE: We do not recommend activating solenoids with this unit without the use of a diode installed between the unit and the solenoid. Directly activating solenoids with this unit will damage the device.

The solid state outputs directly supply voltage to connected devices when commanded via DMX. The voltage (12 or 24) you power the decoder with determines the voltage that will be sent to the solid state outputs. So if your devices require 12V then get a 12V power supply, or if they require 24V then get a 24V power supply. To determine the appropriate amperage of the power supply you will need to add up the requirements of each device that will be connected to the decoder and then an additional 300mA for decoder itself. Contact us if you need assistance.

Specifications

Power Input: DC 12v-24V (max 72 AMP)
Output: Max 3 AMP per channel
Controller: DMX512 3P
